mi::neuraylib::ICanvas Class Reference
[Miscellaneous]
Description
Abstract interface for a canvas represented by a rectangular array of tiles. A canvas represents a two-dimensional array of pixels. The size of this array is given by mi::neuraylib::ICanvas_base::get_resolution_x() and mi::neuraylib::ICanvas_base::get_resolution_y(). The pixels are grouped in rectangular tiles of size get_tile_resolution_x() and get_tile_resolution_y(). The number of tiles is given by get_tiles_size_x() and get_tiles_size_y() and it holds
get_tiles_size_x() * get_tile_resolution_x() >= get_resolution_x() get_tiles_size_y() * get_tile_resolution_y() >= get_resolution_y()
If the left-hand side is strictly larger than the right hand side then there are excess pixels which might have any color.
A pixel at position (canvas_pixel_x, canvas_pixel_y) of the canvas belongs to the tile (tile_number_x, tile_number_y) where tile_number_x and tile_number_y are computed as follows:
tile_number_x = canvas_pixel_x / get_tile_resolution_x() tile_number_y = canvas_pixel_y / get_tile_resolution_y()
Within this tile the pixel has the coordinates (tile_pixel_x, tile_pixel_y) which are computed as follows
tile_pixel_x = canvas_pixel_x % get_tile_resolution_x() tile_pixel_y = canvas_pixel_y % get_tile_resolution_y()
Optionally, there can be multiple layers of such tile arrays. The number of these layers is given by get_layers_size(). The format a layer, i.e., the type of each pixel in that layer, is described by get_type().
See also:
Public Member Functions
- virtual Float32 get_gamma() const =0
- Returns the gamma value. More...
- virtual Uint32 get_layers_size() const =0
- Returns the number of layers this canvas has.
- virtual const ITile* get_tile( Uint32 pixel_x, Uint32 pixel_y, Uint32 layer = 0) const =0
- Returns the tile which contains a given pixel. More...
- virtual ITile* get_tile( Uint32 pixel_x, Uint32 pixel_y, Uint32 layer = 0) =0
- Returns the tile which contains a given pixel. More...
- virtual Uint32 get_tile_resolution_x() const =0
- Returns the tile size in x direction.
- virtual Uint32 get_tile_resolution_y() const =0
- Returns the tile size in y direction.
- virtual Uint32 get_tiles_size_x() const =0
- Returns the number of tiles in x direction.
- virtual Uint32 get_tiles_size_y() const =0
- Returns the number of tiles in y direction.
- virtual void set_gamma( Float32 gamma) =0
- Sets the gamma value. More...
Member Functions
- virtual Float32 mi::neuraylib::ICanvas::get_gamma() const [pure virtual]
-
Returns the gamma value. The gamma value should be a positive number. Typical values are 2.2 for LDR pixel types, and 1.0 for HDR pixel types.
- virtual Uint32 mi::neuraylib::ICanvas::get_layers_size() const [pure virtual]
-
Returns the number of layers this canvas has.
- virtual const ITile* mi::neuraylib::ICanvas::get_tile( Uint32 pixel_x, Uint32 pixel_y, Uint32 layer = 0) const [pure virtual]
-
Returns the tile which contains a given pixel.
Parameters
- pixel_x
- The x coordinate of pixel with respect to the canvas.
- pixel_y
- The y coordinate of pixel with respect to the canvas.
- layer
- The layer of the pixel in the canvas.
Returns
The tile that contains the pixel, or NULL in case of invalid parameters.
- virtual ITile* mi::neuraylib::ICanvas::get_tile( Uint32 pixel_x, Uint32 pixel_y, Uint32 layer = 0) [pure virtual]
-
Returns the tile which contains a given pixel.
Parameters
- pixel_x
- The x coordinate of pixel with respect to the canvas.
- pixel_y
- The y coordinate of pixel with respect to the canvas.
- layer
- The layer of the pixel in the canvas.
Returns
The tile that contains the pixel, or NULL in case of invalid parameters.
- virtual Uint32 mi::neuraylib::ICanvas::get_tile_resolution_x() const [pure virtual]
-
Returns the tile size in x direction.
- virtual Uint32 mi::neuraylib::ICanvas::get_tile_resolution_y() const [pure virtual]
-
Returns the tile size in y direction.
- virtual Uint32 mi::neuraylib::ICanvas::get_tiles_size_x() const [pure virtual]
-
Returns the number of tiles in x direction.
- virtual Uint32 mi::neuraylib::ICanvas::get_tiles_size_y() const [pure virtual]
-
Returns the number of tiles in y direction.
- virtual void mi::neuraylib::ICanvas::set_gamma( Float32 gamma) [pure virtual]
-
Sets the gamma value.
Note:This method just sets the gamma value. It does not change the pixel data itself.
