Description

A scene element that stores scene-specific settings. There are three different types of options:

• scene-specific options,

• render context-specific options (see mi::neuraylib::IRender_context::set_option()), and

• general rendering options (independent of the scene or the render context, see mi::neuraylib::IRendering_configuration::set_renderer_option()). For all three types there might be options that are common to all render modes as well as options specific for a certain render mode.

This class deals with the first of the three types.

These scene-specific settings are typically exposed as attributes; only a few of them are exposed via explicit methods of this interface. Note that the list of attributes below contains only general options that are supposed to be supported by all render modes. Render modes might support additional options which are not documented here, but in the Iray Programmer's Manual; see sections [:ipmlink iray_photoreal_render_mode Iray Photoreal], [:ipmlink iray_interactive_renderer_mode Iray Interactive], and [:ipmlink iray_realtime_renderer_mode Iray Realtime]. Likewise, render-mode specific limitations in the support of the general options below are documented there.

Attributes

• mi::Sint32 depth_reflect

  Maximum number of nested reflection rays.

• mi::Sint32 depth_refract

  Maximum number of nested refraction rays. This is only used by raytracers.

• mi::Sint32 depth

  Maximum total number of nested rays.

• mi::Sint32 progressive_rendering_samples

  The number of samples to compute in every progressive rendering step. The default is 1.

• mi::Sint32 progressive_rendering_min_samples

  The minimum number of samples per pixel to compute before considering criteria to stop progressive rendering. The default is 4.

• mi::Sint32 progressive_rendering_max_samples

  If this number of samples per pixel has been rendered then stop progressive rendering automatically regardless of any other stop criterion. The default is 100.

• mi::Sint32 progressive_rendering_max_time

  Time in seconds after which progressive rendering should terminate automatically. The default is 3600.

• mi::Float32 progressive_rendering_error_threshold

  If this relative error threshold has been reached progressive rendering is stopped automatically. A value of 0.0 targets perfect quality and won't stop rendering. A value of 0.5 will stop rendering already at a very low quality. The default is 0.05.

• mi::Float64 animation_time

  Defines the current time for all animations in this scene.

• mi::Float32_3 section_plane_normal

  Defines the normal of the section plane that can be used to cull parts of the scene. If this normal is set to (0, 0, 0), section plane culling is disabled completely. This is also the default value. This attribute is deprecated, use section_planes instead (which has precedence over this attribute here).

• mi::Float32_3 section_plane_origin

  Defines a point in space the section plane used for culling goes through. It defaults to (0, 0, 0). Also see section_plane_normal. This attribute is deprecated, use section_planes instead (which has precedence over this attribute here).

• struct Section_plane[N] section_planes or struct Section_plane[] section_planes

  A static or dynamic array of structures of type "Section_plane" which describe sections planes that can be used to cull parts of the scene. A structure of type "Section_plane" has the the following members:

  • mi::Float32_3 origin

    A point in space the section plane goes through. The default is (0, 0, 0).

  • mi::Float32_3 normal

    The normal of the section plane. If this normal is set to (0, 0, 0), the section plane is disabled. This is also the default value.

  • bool clip_light

    Indicates whether the section plane also affects lights (or only geometry). When the parameter is set to true, also the geometry behind the section plane occludes incoming light. The default is false.

  • bool disabled

    Indicates whether the section plane is disabled or not. The default is false.

  This attribute has precedence over the attributes section_plane_normal and section_plane_origin which are deprecated. Render modes might have an internal limit on the number of supported section planes.

• mi::Sint32 filter

  The mode used for sample filtering. See Filter_type for possible values.

• mi::Float32 radius

  The radius of the filter kernel. If set to 0, filtering is turned off.

• mi::IRef environment_function

  The MDL environment of the scene. See the section [:ipmlink environment_dome_and_implicit_groundplane Environment dome and implicit groundplane] in the Iray Programmer's Manual for details.

• mi::Float32 mdl_meters_per_scene_unit

  The conversion ratio between meters and scene units for MDL functions and materials. The default is 1.0.
